The HPS series high voltage DC power supply is a continuously adjustable DC constant voltage constant current power supply with a rated power of 600/1200W. This series of power supplies can be rated up to 12KV and has excellent performance in the same type of products. In addition, the power supply adds remote control detection to the local operation, which greatly improves the flexibility and application of the power supply. This series of power supplies can be widely used in various electronic components aging systems, various test instruments and electronic application laboratories.
| Specification Parameter | HPS0611 / HPSN0611 | HPS0612 / HPSN0612 | HPS0613 / HPSN0613 | HPS0614 / HPSN0614 | HPS0615 / HPSN0615 |
| Rated Voltage | 0~1000V / 0~-1000V | 0~1200V / 0~-1200V | 0~1500V / 0~-1500V | 0~2000V / 0~-2000V | 200~3000V / -200~-3000V |
| Rated Current | 0~600mA | 0~500mA | 0~400mA | 0~300mA | 0~200mA |
| Voltage Display Accuracy | ≤0.2%+2LSB | ≤0.2%+2LSB | ≤0.2%+2LSB | ≤0.2%+2LSB | ≤0.2%+2LSB |
| Ripple | ≤0.05% FS | ≤0.05% FS | ≤0.05% FS | ≤0.1% FS | ≤0.1% FS |
| Specification Parameter | HPS1216 / HPSN1216 | HPS1217 / HPSN1217 | HPS1218 / HPSN1218 | HPS1219 / HPSN1219 | HPS1220 / HPSN1220 |
| Rated Voltage | 200~4000V / -200~-4000V | 300~5000V / -300~-5000V | 500~6000V / -500~-6000V | 500~8000V / -500~-8000V | 800~10KV / -800~-10KV |
| Rated Current | 0~300mA | 0~240mA | 0~200mA | 0~150mA | 0~120mA |
| Current Display Accuracy | ≤0.5%+2LSB | ≤0.5%+2LSB | ≤0.5%+2LSB | ≤0.5%+2LSB | ≤0.5%+2LSB |
| Ripple | ≤0.1% FS | ≤0.1% FS | ≤0.1% FS | ≤0.1% FS | ≤0.1% FS |
